Weight and Dimensions: 1.5 kg (including battery), 25 cm x 28 cm x 9 cm Detector: Graphene window silicon drift detector (SDD) with a 20mm² active area and typical resolution <145eV @450,000cps Elemental Range: Capable of analyzing elements from Magnesium (Mg) to Uranium (U) Excitation: 6-50kV X-ray tube. Spot Size: Collimator options of 8mm standard, with 5mm or 3mm optional…
Elemental Range: Measures from Mg to U Excitation: 29kV; No filter Detector: Graphene window silicon drift detector (SDD) Resolution: < 145 eV at 450,000 cps X-ray Tube: Rh target, 4W, 6-50 kV, 5-200 µA Collimator (Spot Size): 8 mm Weight: Approximately 1.5 kg (3.3 lbs) including battery Battery: Li-Ion, 7.2 V nominal Display: 3.7-inch LCD touchscreen with 640 x 480…
